Microtest 6366 LCR Metre Test Frekansı : 10Hz-500kHz

Test Frekansı 10Hz-500kHz Çıkış Empedansı 100Ω Açık Devre/Kısa Devre Sayaç Modu Liste Modu 0″ TFT, 800×480 renkli ekran Aynı Anda Görüntülenen Dört Parametre Karşılaştırıcı/BIN Temel Doğruluk ±0.05% PC Link ile Grafik Analizi Kullanma RS-232, İşleyici, LAN, USB Ana Bilgisayar, İşleyici, GPIB SPECİFİCATİONS Selection Model 6366 Frequency 10Hz-500kHz Selection 6365B 6365A… Devamı

Test Frekansı 10Hz-500kHz
Çıkış Empedansı 100Ω
Açık Devre/Kısa Devre
Sayaç Modu
Liste Modu
0″ TFT, 800×480 renkli ekran
Aynı Anda Görüntülenen Dört Parametre
Karşılaştırıcı/BIN
Temel Doğruluk ±0.05%
PC Link ile Grafik Analizi Kullanma
RS-232, İşleyici, LAN, USB Ana Bilgisayar, İşleyici, GPIB

SPECİFİCATİONS

Selection

Model	6366
Frequency	10Hz-500kHz
Selection	6365B	6365A	6363	6364	6365	6367
Frequency Range	1mHz- 200kHz	0.1Hz- 200kHz	10Hz- 20kHz	10Hz- 100kHz	10Hz- 200kHz	10Hz- 1MHz

SPEC

Model	6366
Frequency Range	10Hz-500kHz
Frequency Setting	Continuity
Frequency Output Accuracy	±0.01%
Frequency Resolution	5 Digits
Basic Accuracy	± 0.05%
AC Drive Level	Test Signal Voltage Level	10mV – 2Vrms
	Voltage Minimum Resolution	1mV
DC Drive Level	Test Signal Voltage Level	10mV – 2V
	Voltage Minimum Resolution	1mV
Output Impedance	100 Ω
Measurement Mode	Meter mode, list mode
Measurement Parameters	\|Z\|、\|Y\|、θ、X、R、G、B、L、D、Q、DCR、C
Test Time	AC / DC test speed Max. 8mS

Measurement Parameters

Parameters	Range
\|Z\|	0.001mΩ – 99.999MΩ
R, X	0.001mΩ – 99.999MΩ
\|Y\|	0.1nS – 99.999S
G, B	0.1nS – 99.999S
θ	±0.001 ~ ±180.000deg
Cs, Cp	0.01pF – 9.9999F
Ls, Lp	0.1nH – 99.999KH
D	0.00001 – 9.9999
Q	0.1 – 9999.9
Δ	-9999% – 9999%
Rdc	0.001mΩ – 99.999MΩ

SYSTEM

Measurement Circuit	Series/Parallel
Correction	Open Circuit/Short Circuit
Indicator	PASS/FAIL
Test Range	Automatic/Lock
BIN	●
List Mode	8 sets
Bulit-in Storge	128 sets
USB Host Storge	LCR setting documents, list mode setting document
Trigger Test	Auto, manual, RS-232, GPIB, Handler
Power Supply	Voltage：98-132Vac or 195-264Vac (Switchable)
Power Supply	Frequency：47-63Hz
Power consumption	30VA
Environment	Temperature：10℃-40℃
Environment	Humidity：20-90%RH
Dimension	358x148x343 mm (WHD)
Weight	3 Kg
Interface	RS-232、Handler、LAN、USB Host
Display	Color Screen, 7″ TFT (800*480)

Teklif İsteyinMicrotest 6366 LCR Metre Test Frekansı : 10Hz-500kHz için uzman ekibimizden bilgi almak ve fiyatlar için hemen iletişime geçin!

Kategoriler: Dijital Masa Tipi LCR Metreler, LCR Metreler Etiketler: LCR, LCR Metre, Microtest

Açıklama

Model	6366
Frequency	10Hz-500kHz
Selection	6365B	6365A	6363	6364	6365	6367
Frequency Range	1mHz- 200kHz	0.1Hz- 200kHz	10Hz- 20kHz	10Hz- 100kHz	10Hz- 200kHz	10Hz- 1MHz

Model	6366
Frequency Range	10Hz-500kHz
Frequency Setting	Continuity
Frequency Output Accuracy	±0.01%
Frequency Resolution	5 Digits
Basic Accuracy	± 0.05%
AC Drive Level	Test Signal Voltage Level	10mV – 2Vrms
	Voltage Minimum Resolution	1mV
DC Drive Level	Test Signal Voltage Level	10mV – 2V
	Voltage Minimum Resolution	1mV
Output Impedance	100 Ω
Measurement Mode	Meter mode, list mode
Measurement Parameters	\|Z\|、\|Y\|、θ、X、R、G、B、L、D、Q、DCR、C
Test Time	AC / DC test speed Max. 8mS

Parameters	Range
\|Z\|	0.001mΩ – 99.999MΩ
R, X	0.001mΩ – 99.999MΩ
\|Y\|	0.1nS – 99.999S
G, B	0.1nS – 99.999S
θ	±0.001 ~ ±180.000deg
Cs, Cp	0.01pF – 9.9999F
Ls, Lp	0.1nH – 99.999KH
D	0.00001 – 9.9999
Q	0.1 – 9999.9
Δ	-9999% – 9999%
Rdc	0.001mΩ – 99.999MΩ

Measurement Circuit	Series/Parallel
Correction	Open Circuit/Short Circuit
Indicator	PASS/FAIL
Test Range	Automatic/Lock
BIN	●
List Mode	8 sets
Bulit-in Storge	128 sets
USB Host Storge	LCR setting documents, list mode setting document
Trigger Test	Auto, manual, RS-232, GPIB, Handler
Power Supply	Voltage：98-132Vac or 195-264Vac (Switchable)
Power Supply	Frequency：47-63Hz
Power consumption	30VA
Environment	Temperature：10℃-40℃
Environment	Humidity：20-90%RH
Dimension	358x148x343 mm (WHD)
Weight	3 Kg
Interface	RS-232、Handler、LAN、USB Host
Display	Color Screen, 7″ TFT (800*480)

Ürün Özellikleri

Teknik Özellikler

DATASHEET

Aksesuarlar

MICROTEST Hakkında

Tayvan merkezli Microtest Corporation, pasif bileşenler, transformatörler, kablolar ve motorlar gibi çeşitli elektronik ürünlerin testi için LCR metreler, empedans analizörleri, elektriksel güvenlik test cihazları ve otomatik test sistemleri de dahil olmak üzere kapsamlı ve yüksek hassasiyetli ölçüm çözümleri üreten bir markadır.
