| Function | Range | Accuracy |
| DC Voltage | 600.0 V ... 1000.0 V | ±(0.8% of reading + 5 digits) |
AC Voltage (50 Hz ... 400 Hz) | 600.0 V ... 1000.0 V | From ±(0.8% of reading + 5 digits) to ±(10% of reading + 5 digits) |
DC+AC Voltage (DC, 50 Hz ... 400 Hz) | 600.0 V ... 1000.0 V | From ±(1.0% of reading + 7 digits) to ±(12% of reading + 7 digits) |
| PEAK-rms (ACV & ACA) | Response: 80 ms to > 90%. |
| CREST (Peak-Hold) | Accuracy: Add 250 digits to specified accuracy for changes > 5ms |
| Audible Continuity Tester | Audible Threshold: At between 10 Ω and 250 Ω. Response time: 32 ms approx. |
| Ohm | 600.0 Ω, 6.000 kΩ, 60.00 kΩ | ±(1.0% of reading + 5 digits) |
| Capacitance | 200.0 μF, 2500 μF | ±(2.0% of reading + 4 digits) |
| Diode Tester | 2.000 V | ±(1.5% of reading + 5 digits) |
| AmpTipTM clamp-on DCA | 00.00 A … 60.00 A | From ±(1.5% of reading + 5 digits) to ±(3.0% of reading + 5 digits) |
| AmpTipTM clamp-on ACA (40 Hz ... 400 Hz) | 00.00 A … 60.00 A | From ±(1.5% of reading + 5 digits) to ±(3.0% of reading + 5 digits) |
| AmpTipTM clamp-on DC+ACA (DC, 40 Hz ... 400 Hz) | 00.00 A … 60,00 A | From ±(2.0% of reading + 7 digits) to ±(3.0% of reading + 7 digits) |
| Regular Clamp-on DCA | 60.00 A … 1000 A | ±(1.8% of reading + 5 digits) |
| Regular Clamp-on ACA (40 Hz ... 400 Hz) | 60.00 A … 1000 A | From ±(1.8% of reading + 5 digits) to ±(2.2% of reading + 5 digits) |
| Regular Clamp-on DC+ACA (DC, 40 Hz ... 400 Hz) | 60.00 A … 1000 A | From ±(2.2% of reading + 7 digits) to ±(2.5% of reading + 7 digits) |
| Hz Line Level Frequency | 5.00 Hz … 999.9 Hz | ±(1.0% of reading + 5 digits) |
| Non-Contact EF-Detection | 20 V … 440 V | Tolerance: 10 V … 1000 V |
| Detection Frequency | 50/60Hz |
| Transient Protection | 8.0 kV (1.2/50 µs surge) |
| Overload Protections | Current & Hz functions via jaws: 1000 ADC/AAC rms at < 400 Hz Other functions via terminals: 1000 VDC/VAC rms |
| Power Supply | 1.5 V AAA Size battery X 2 |
| Power Consumption | Typical 13 mA for Current functions |
| Dimension (L x W x H) | 258 x 94 x 44 mm |
| Weight | 392 g |
| Jaw opening & Conductor diameter | 51 mm max |
