SPARK P3 Kısmi Deşarj ve EMI Analizörü

Doble Spark P3, yüksek gerilim ekipmanlarının arızalanmasına neden olabilecek yalıtım sistemi bozulmalarını tanımlamak için yazılım destekli bir radyo sinyali detektörü kullanan PD ve EMI analizörüdür. PD ve EMI analizleri için 9 kHz ila 2 GHz ve akustik/referans gerilim ölçümleri için DC ila 500kHz frekans aralığında uygun sensörlerden gelen sinyalleri algılar.

Insulation system diagnostics for high-voltage assets

Doble Spark P3 is a universal partial discharge (PD) and electromagnetic interference (EMI) analyzer that uses a software defined radio signal detector to identify characteristics of insulation system deterioration that could lead to the failure of high voltage equipment. It detects signals from suitable sensors in a frequency range between 9 kHz to 2 GHz for PD and EMI, and DC to 500k Hz for acoustic and reference voltage measurements.

A comprehensive range of detectors, acquisition and analysis tools enables users of all levels to acquire and review partial discharge and EMI signals, covering a wide range of test objects and usable sensors, including:

• Rotating machines (PD couplers, HFCT sensors)
• Power transformers (HFCT sensors, UHF antennas, acoustic microphones)
• Instrument transformers (HFCT sensors)
• Switchgear (GIS and AIS – TEV sensors, UHF antennas, HFCT, acoustic sensors, spacer
  sensors, window sensors)
• Cables and accessories (HFCT, UHF sensors, acoustic sensors)
