The Model 590G-V2 is a modestly priced, lightweight field portable instrument designed to audit P.T. and C.T. installations in a utility system. The Model 590G-V2 is used for many routine workshop tests, as well as field testing, to an accuracy of 0.02%. It is optimised for testing metering C.T.s, but can also test protection C.T.s for current and phase error at normal burden.The 590G-V2 has all the features and advantages of the previous models with additional testing features, better accuracy and smaller size and weight.
- C.T. Ratio Error Measurement
- P.T. Ratio Error Measurement (No Load)
- Burden Measurement
- Admittance Measurement
